SSSU系列——ALPS滑動開關
鍵種類豐富的大型通用型，操作方向：Vertical Horizontal ? 安裝高度：8.5mm ? 行程：3.0mm ? 最大額定值：0.1A 30V DC ? 電路數：1/2/4-poles。
產品詳情
我司是ALPS授權代理商，ALPS系列產品均有在售，需要了解價格、包裝數，交期以及產品資料請咨詢?cè)诰€(xiàn)客服！
|
產品編號 |
照片 |
行程 |
操作部方向 |
操作部長度 |
電路數 |
接點數 |
動作力 |
安裝方法 |
切換時限 |
焊接方法 |
尺寸(W×D×H) |
|
SSSU011700 |
 |
3.0mm |
Vertical |
6.0mm |
1 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
18.5×7.0×8.5mm |
|
SSSU012200 |
 |
3.0mm |
Vertical |
9.0mm |
1 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
18.5×7.0×8.5mm |
|
SSSU014800 |
 |
3.0mm |
Vertical |
6.0mm |
1 |
3 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
24.5×7.0×8.5mm |
|
SSSU015100 |
 |
3.0mm |
Vertical |
9.0mm |
1 |
3 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
24.5×7.0×8.5mm |
|
SSSU022400 |
 |
3.0mm |
Vertical |
6.0mm |
2 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
18.5×7.0×8.5mm |
|
SSSU022800 |
 |
3.0mm |
Vertical |
9.0mm |
2 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
18.5×7.0×8.5mm |
|
SSSU025800 |
 |
3.0mm |
Vertical |
6.0mm |
2 |
3 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
24.5×7.0×8.5mm |
|
SSSU026300 |
 |
3.0mm |
Vertical |
9.0mm |
2 |
3 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
24.5×7.0×8.5mm |
|
SSSU041700 |
 |
3.0mm |
Vertical |
6.0mm |
4 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
21.5×7.0×8.5mm |
|
SSSU042100 |
 |
3.0mm |
Vertical |
9.0mm |
4 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
21.5×7.0×8.5mm |
|
SSSU111400 |
 |
3.0mm |
Horizontal |
6.0mm |
1 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
18.5×7.0×8.5mm |
|
SSSU113200 |
 |
3.0mm |
Horizontal |
6.0mm |
1 |
3 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
24.5×7.0×8.5mm |
|
SSSU121700 |
 |
3.0mm |
Horizontal |
6.0mm |
2 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
18.5×7.0×8.5mm |
|
SSSU122200 |
 |
3.0mm |
Horizontal |
9.0mm |
2 |
2 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
18.5×7.0×8.5mm |
|
SSSU124900 |
 |
3.0mm |
Horizontal |
9.0mm |
2 |
3 |
Refer to the dimensions. |
Snap-in (t1.6) |
Non shorting |
Manual, Dip |
24.5×7.0×8.5mm |
SSSU系列用途：
Audio / TV:音響
